Industrial DC Servo Drive
We are committed to providing customers with customized, integrated intelligent solutions to meet the personalized needs of different fields. We have developed a diversified range of servo drives, which are characterized by their small size, high power density, rich interfaces, easy installation, simple debugging, and high reliability.The minimum size is 18*28*5mm, with a current range of 1-30A and a voltage range of 8-100VDC.
The product is suitable for precision speed control and positioning systems that require rapid response. It can be used to drive robot systems, electronic/semiconductor equipment, automated guided vehicles (AGV), intelligent warehouses, and various types of automated production equipment.
Product model and parameter list:
Specifications | PIQ | PIM | PIU | PID | PIH | |||||
Continuous Current A | 1/2 | 2/5 | 5/10 | 3/10/25/50/80 | 5/10/15/20 | |||||
Supply Voltage VDC | 8-30 | 12-40 | 12-40 | 18-100 | 18-100 | |||||
Communications | CANopen、EtherCAT | |||||||||
Feedbacks Types | Incremental encoder (single ended/differential signal), digital Hall, SSI, BISS-C, Tamagawa NRZ | |||||||||
Motion Modes | Torque, speed, position, homing, IP, CSP, CSV, CST | |||||||||
Motor Types | Servo motor, DC brushless, brushed motor, linear motor, torque motor, coreless motor | |||||||||
Digital I/O | 1 inputs 1 outputs | 2 inputs 2 outputs | 1 inputs 1 outputs | 6 inputs 1 outputs | 4 inputs 2 outputs | |||||
Operating temp. | -20°C~+60°C | |||||||||
Storage temp. | -30°C~+70°C | |||||||||
Dimensions mm | 28x18x5 | 49x15x6 | 27x27x10 | 61x35x33 | 111x76x45 | |||||
Weight ~ | 6 g | 14 g | 18 g | 150 g | 225 g | |||||
